Choudhary Metals is a trusted importer, exporter, and supplier of premium non-ferrous and ferrous metals, serving diverse industries worldwide. With a strong focus on quality and reliability, we deliver copper, brass, aluminium, bronze, and other metals in various forms to meet every industrial need.
| Alloy 5454 | Spec: BS EN 573-3:2009 |
|---|---|
| Chemical Element | % Present |
| Manganese (Mn) | 0.50 - 1.00 |
| Iron (Fe) | 0.0 - 0.40 |
| Magnesium (Mg) | 2.40 - 3.00 |
| Silicon (Si) | 0.0 - 0.25 |
| Chromium (Cr) | 0.05 - 0.20 |
| Titanium (Ti) | 0.0 - 0.20 |
| Zinc (Zn) | 0.0 - 0.25 |
| Copper (Cu) | 0.0 - 0.10 |
| Other (Each) | 0.0 - 0.05 |
| Others (Total) | 0.0 - 0.15 |
| Aluminium (Al) | Balance |
| Physical Property | Value |
|---|---|
| Density | 2.69 g/cm³ |
| Melting Point | 645 °C |
| Thermal Expansion | 23.6 x10^-6 /K |
| Modulus of Elasticity | 70.5 GPa |
| Thermal Conductivity | 135 W/m.K |
| Electrical Resistivity | 34 % IACS |
| Spec: BS EN 485-2:2008 | Sheet - 0.2mm to 6.0mm |
|---|---|
| Mechanical Property | Value |
| Proof Stress | 85 Min MPa |
| Tensile Strength | 215 - 275 MPa |
| Hardness Brinell | 58 HB |
