An unalloyed ('pure') non-heat treatable rolled aluminium sheet engineered for
general sheet metal work in which excessive mechanical residences are not required.
Internationally acknowledged grade EN AW 1050A H14 – 99.50% pure aluminium (AL 99.5) sheet
pressure hardened to the half-hard temper. The preceding BS specification turned into called S1B
and the half of-hard temper was called H4, giving S1B H4. Choudhary Metal Distributor range of 1050A will
meet all suitable countrywide/global standards.
Machining
Pure aluminium has most effective honest machinability due to the softness of the
alloy. The half-hard temper will increase the hardness over the annealed/gentle base alloy but
could not be defined as free chipping as compared to the harder, alloyed aluminium's.
We recommend aluminium geometry slicing equipment walking at an inexpensive speed to keep away
from the threshold construct-up which could arise at lower reducing speeds. Excessive pace steel
equipment may be greater within your means than carbide, specifically with the possibility of a
huge rake attitude on machines which cannot attain carbide reducing speeds.
Specification
Choudhary Metal Distributor Stock Aluminium flat rolled product is most commonly specified
to ASTM B209M. Product designated as plate for ship building in very specific alloys and tempers
in compliance with ASTM B928M.
Typical Applications
• General sheet metal work
• Packaging
• Boiler making
• Heat transfer devices
• Kitchenware
• Chemical industry
• Pharmaceutical industry
• Automotive industry
• Architecture
• Cabinets
• Appliances
• Vessels
• Panelling
Technical Data Sheet
| Chemical Composition Limits |
| Weight% |
Si |
Fe |
Cu |
Mn |
Mg |
Zn |
Ti |
Al |
V |
Others |
| 1050A EAA |
0.25 max |
0.40 max |
0.05 max |
0.05 max |
0.05 max |
0.07 max |
0.05 max |
99.5 min |
- |
0.03 |
| 1050 USA |
0.25 max |
0.40 max |
0.05 max |
0.05 max |
0.05 max |
0.05 max |
0.03 max |
99.5 min |
0.05 |
0.03 |
Typical Mechanical Properties
| Material |
Temper |
Tensile Strength (N/mm²) |
Yield Strength (N/mm²) |
Elongation in 50mm (%) |
| 1050 Bar |
F |
60 (min) |
- |
23 |
We offer 1050A aluminium alloy in sheet.
Processing
Choudhary Metal Distributor provide an in-house processing service include guillotining
where we can cut your aluminium sheet to your specific size requirement.
