Choudhary Metals is a trusted importer, exporter, and supplier of premium non-ferrous and ferrous metals, serving diverse industries worldwide. With a strong focus on quality and reliability, we deliver copper, brass, aluminium, bronze, and other metals in various forms to meet every industrial need.
| Model | Size | Section area | Weight | ||||||
|---|---|---|---|---|---|---|---|---|---|
| A | B | t1 | t2 | r1 | r2 | A | M | ||
| mm | Cm2 | Kg/m | |||||||
| 200×90 | L200×90×8×14 | 200 | 90 | 8 | 14 | 14 | 7 | 27.80 | 21.8 |
| L200×90×9×14 | 9 | 29.66 | 23.3 | ||||||
| L200×90×10×14 | 10 | 31.52 | 24.7 | ||||||
| 250×90 | L250×90×9×14 | 250 | 90 | 9 | 14 | 17 | 8.5 | 34.31 | 26.9 |
| L250×90×9×15 | 9 | 15 | 35.12 | 27.6 | |||||
| L250×90×10×15 | 10 | 15 | 37.47 | 29.4 | |||||
| L250×90×11×16 | 11 | 16 | 40.61 | 31.9 | |||||
| L250×90×12×16 | 12 | 16 | 42.95 | 33.7 | |||||
| 300×90 | L300×90×10×16 | 300 | 90 | 10 | 16 | 19 | 9.5 | 43.38 | 34.1 |
| L300×90×11×16 | 11 | 46.22 | 36.3 | ||||||
| L300×90×12×17 | 12 | 17 | 49.84 | 39.1 | |||||
| L300×90×13×17 | 13 | 52.67 | 41.3 | ||||||
| 350×100 | L350×100×11×17 | 350 | 100 | 11 | 17 | 22 | 11 | 54.41 | 42.7 |
| L350×100×12×17 | 12 | 57.74 | 45.3 | ||||||
| 400×100 | L400×100×11.5×16 | 400 | 100 | 11.5 | 16 | 24 | 12 | 61.09 | 47.9 |
| L400×100×12×18 | 12 | 18 | 64.7 | 50.8 | |||||
| L400×100×13×18 | 13 | 68.59 | 53.8 | ||||||
| 450×125 | L450×125×11.5×18 | 450 | 125 | 11.5 | 18 | 24 | 12 | 73.11 | 57.4 |
